X-t ract Probe
A Bold Probing into Spectacular Marvels
The name 'X-tract' is inspired by the word 'extract,' meaning 'to draw out the essence.' Its slender design allows it to easily access narrow, hidden spaces, capturing microscopic details invisible to the naked eye and transforming them into stunning imagery.
Combining a T8 large aperture, wide-angle zoom macro capabilities, and a design inspired by starship exploration, it redefines macro cinematography. The X-tract lens becomes a tool for exploration and discovery, extracting unique visual creativity from unknown dimensions and perspectives.
Unprecedented Vision with Probe Zoom
The X-tract 18-28mm T8 wide-angle probe zoom series redefines the possibilities of macro cinematography. Featuring a combination of 0°,90° and 360º lenses, it offers boundless creative flexibility. The X-tract probe zoom covers essential focal lengths for commercial filming, enabling effortless adjustments even in confined spaces while delivering enhanced spatial depth and dimensional detail that redefines probe lens capabilities. This flexibility empowers filmmakers with exceptional adaptability and creative expression.
Unprecedented Vision with Probe Zoom
The X-tract 18-28mm T8 wide-angle probe zoom series redefines the possibilities of macro cinematography. Featuring a combination of 0°,90° and 360º lenses, it offers boundless creative flexibility. The X-tract probe zoom covers essential focal lengths for commercial filming, enabling effortless adjustments even in confined spaces while delivering enhanced spatial depth and dimensional detail that redefines probe lens capabilities. This flexibility empowers filmmakers with exceptional adaptability and creative expression.
Masterful Optical Balance for
Immaculate Visuals
X-tract 18-28mm T8 0° lens features 7 high-refractive-index (HRI) lenses and 6 extra-low-dispersion (ED) lenses, striking an optimal balance between size and weight while minimizing chromatic aberrations, distortions, and optical flaws common in probe lenses. Its innovative differential distribution of HRI lens delivers prime-level image quality and accurate color temperature, effectively reducing the yellowish tint commonly seen in other probe lenses. Distortion is kept within ±2% across the entire zoom range, with near-zero distortion and focus breathing at 24mm, ensuring precise rendering of intricate micro-details.
Masterful Optical Balance for
Immaculate Visuals
X-tract 18-28mm T8 0° lens features 7 high-refractive-index (HRI) lenses and 6 extra-low-dispersion (ED) lenses, striking an optimal balance between size and weight while minimizing chromatic aberrations, distortions, and optical flaws common in probe lenses. Its innovative differential distribution of HRI lens delivers prime-level image quality and accurate color temperature, effectively reducing the yellowish tint commonly seen in other probe lenses. Distortion is kept within ±2% across the entire zoom range, with near-zero distortion and focus breathing at 24mm, ensuring precise rendering of intricate micro-details.
More Dimensions, Greater Creativity
The combination of prism structure and 360° rotating ring, offering an additional dimension for creative adjustments and providing a more immersive macro experience. The entire series features a smooth 300° focus throw, tested for high-frequency durability and micron-level assembly precision, enabling precise focus shifts and more flexible depth of field control. The X-tract lenses feature a par-focal design, locking the focus during zooming. Whether capturing subtle movements or quickly changing focal lengths, the focus remains sharp, delivering the classic Hitchcock dolly zoom effect even in macro shooting.
Note: Images captured with the 90° lens require Mirror Flip.
More Dimensions, Greater Creativity
The combination of prism structure and 360° rotating ring, offering an additional dimension for creative adjustments and providing a more immersive macro experience. The entire series features a smooth 300° focus throw, tested for high-frequency durability and micron-level assembly precision, enabling precise focus shifts and more flexible depth of field control. The X-tract lenses feature a par-focal design, locking the focus during zooming. Whether capturing subtle movements or quickly changing focal lengths, the focus remains sharp, delivering the classic Hitchcock dolly zoom effect even in macro shooting.
Note: Images captured with the 90° lens require Mirror Flip.
Unmatched Performance Beyond Primes
The X-tract series features native breath control, reducing breathing effects to just 0.5% at the 24mm (compared to 39.2% in other 24mm probe primes). The focus breathing becomes virtually imperceptible, minimizing the need for post-production adjustments. This ensures seamless visual continuity and stability during focus shifts, delivering immersive and spectacular cinematic visuals. The X-tract 0° probe zoom maintains a relative illumination of 70.7%, while the 90° probe zoom offers 68.6% (compared to 54.9% in other 24mm probe primes), ensuring consistent brightness and delivering professional-grade visual performance.
Unmatched Performance Beyond Primes
The X-tract series features native breath control, reducing breathing effects to just 0.5% at the 24mm (compared to 39.2% in other 24mm probe primes). The focus breathing becomes virtually imperceptible, minimizing the need for post-production adjustments. This ensures seamless visual continuity and stability during focus shifts, delivering immersive and spectacular cinematic visuals. The X-tract 0° probe zoom maintains a relative illumination of 70.7%, while the 90° probe zoom offers 68.6% (compared to 54.9% in other 24mm probe primes), ensuring consistent brightness and delivering professional-grade visual performance.
0.0%
0.0%
Breathing Effect
0.0%
0.0%
RI of 0° Lens
0.0%
0.0%
RI of 90° Lens
0.0%
0.0%
RI of 360° Lens
360° Periscope: Spin Into Future
The X-tract 360° probe lens unlock three shooting modes for creative flexibility: Front Mode (0°): 30cm probe shaft moves in a 55cm arc for smooth vertical shots in tight spaces. Oblique Mode (0-180°): Dual rotation rings enable Dutch angles and horizon adjustments without quality loss.
Rear Mode (180°): Foldable design with 360° rotation for dramatic "barrel roll" effects in confined areas.
360° Periscope: Spin Into Future
The X-tract 360° probe lens unlock three shooting modes for creative flexibility: Front Mode (0°): 30cm probe shaft moves in a 55cm arc for smooth vertical shots in tight spaces. Oblique Mode (0-180°): Dual rotation rings enable Dutch angles and horizon adjustments without quality loss.
Rear Mode (180°): Foldable design with 360° rotation for dramatic "barrel roll" effects in confined areas.
Ultra-Macro, Unlocking a New world
With a maximum magnification ratio of 2.1:1, the X-tract reveals the intricate textures of everyday objects and creates stunning, highly detailed visuals. When capturing tiny objects like insect wings, water droplets, sand grains, and miniature items, it brings out microscopic structures that are often invisible to the naked eye. The minimum focusing distance is reduced from the traditional 56.3cm (1'11") of probe lenses to 47.3cm (1'6"), with a minimum working distance of just 6mm (0.2"), allowing the lens to almost touch the subject for finer macro details.
Ultra-Macro, Unlocking a New world
With a maximum magnification ratio of 2.1:1, the X-tract reveals the intricate textures of everyday objects and creates stunning, highly detailed visuals. When capturing tiny objects like insect wings, water droplets, sand grains, and miniature items, it brings out microscopic structures that are often invisible to the naked eye. The minimum focusing distance is reduced from the traditional 56.3cm (1'11") of probe lenses to 47.3cm (1'6"), with a minimum working distance of just 6mm (0.2"), allowing the lens to almost touch the subject for finer macro details.
0.0:1
0.0:1
Magnification
0.0mm/
0.0mm/
0.0"
0.0"
Working Distance
0.0cm/1'6"
0.0cm/1'6"
Focusing Distance
Modular System for Easy Detachment
The specially designed inter-lens mount system delivers exceptional flexibility for detachable kits, enabling seamless transitions from pre-production to on-location shooting. It accommodates diverse team requirements while providing expanded framing options. A modular, detachable version is also available. it offers greater flexibility and reliable support for creative workflows.
*Note: The detachable model cannot be upgraded to a complete unit. The fixed model cannot be disassembled or interchanged.
Modular System for Easy Detachment
The specially designed inter-lens mount system delivers exceptional flexibility for detachable kits, enabling seamless transitions from pre-production to on-location shooting. It accommodates diverse team requirements while providing expanded framing options. A modular, detachable version is also available. it offers greater flexibility and reliable support for creative workflows.
*Note: The detachable model cannot be upgraded to a complete unit. The fixed model cannot be disassembled or interchanged.
Ultimate Protection,
Ready for Any Challenge
Ultimate Protection,
Ready for Any Challenge
Constructed from aerospace-grade aluminum alloy, the lens is lightweight yet robust. A 25μm anodized coating enhances the body’s hardness, improving abrasion resistance and corrosion protection. Tested under extreme temperatures from -30°C to 70°C, it ensures stability and durability in challenging shooting environments. With IP57-rated dust and water resistance, the lens body is waterproof to over 28 cm. The front lens element features a hydrophobic anti-fog coating, reducing water and fog accumulation for consistently clear imagery.
Constructed from aerospace-grade aluminum alloy, the lens is lightweight yet robust. A 25μm anodized coating enhances the body’s hardness, improving abrasion resistance and corrosion protection. Tested under extreme temperatures from -30°C to 70°C, it ensures stability and durability in challenging shooting environments. With IP57-rated dust and water resistance, the lens body is waterproof to over 28 cm. The front lens element features a hydrophobic anti-fog coating, reducing water and fog accumulation for consistently clear imagery.
0.0μm
0.0μm
Anodized Coating
-0.0~
-0.0~
0.0℃
0.0℃
Testing in harsh environments
0.0cm
0.0cm
Waterproof Depth
IP0
IP0
Protection Rating
Agile and Flexible,Fully Controllable
Agile and Flexible,Fully Controllable
Weighing only 1.09–1.14kg, the 0° measures 41.5cm in the length with a 29.6mm front diameter, the 90º measures 42.1cm in the length, and the 360° periscope model features a 16cm crossarm and 30cm lens arm. Periscope models share a 37.7×30.58mm square front filter.Compared to bulky macro setups, this slim tube design offers superior flexibility and adaptability. The rear-heavy design shifts the lens' balance closer to the camera body, making it easier to maintain stability whether handheld or on a stabilizer use, reducing shake and enabling precise focus and zoom adjustments. When used with sliders or robotic arms for large-range movements, it offers superior control precision, minimizing post-production adjustments.
0.00~
0.00~
0.00kg
0.00kg
Weight
Cine-standard Crafts,
Precise and Reliable
With a 28cm water immersion depth, dual-sided hydrophobic coated UV filter, and O-shaped clamp, the lens ensures stability and versatility during challenging shoots. The X-tract features a 360° rotating ring, ensuring seamless compatibility with professional cinema equipment and accessories. Optional follow-focus accessories effectively manage rotational focus adjustments. The rotating ring allows for easy adjustment of the lens angle, enabling quick correction of the frame's horizontal alignment to ensure precise composition.
Clear markings for magnification ratio, waterproof lines, and rotation scales on the lens body further improve usability, offering filmmakers a seamless and intuitive shooting experience. The native PL mount features rear elements that protrude just 1.37 cm from the mounting flange. This short rear protrusion is compatible with DZOFILM Octopus and most PL-E/RF/LPL adapters and Speedboosters.
“
The DZOFilm X-Tract's wide T8 aperture is a game-changer for tabletop and product work, offering incredible depth of field control and capturing stunning details.
What sets the Probe Zoom X-Tract apart is its ability to combine macro precision with the creative flexibility of a zoom, delivering stunning image quality with a beautifully creamy bokeh, especially at 28mm.
The DZOFILM X-Tract Zoom Probe Lens sets a new benchmark in the market.
”
Baptiste Lejeune
Videographer/Content Creator
Stepping into the world of macro with the DZOFilm X-Tract 18-28mm T8 FF Probe Zoom Lens has been nothing short of impressive. The lens's impressive 2.1:1 magnification and incredibly close 6mm working distance have opened up a universe of detail I never thought possible. It's like being able to touch the subject and still capture its finest textures and details.
On top of that, the build quality of the X-Tract lens is remarkably solid, and its waterproof barrel enables you to explore unique perspectives.
Alex Grima
Food & Drink Director
The Probe Zoom X-Tract is a revolutionary tool for tabletop and macro cinematography. Its ability to smoothly transition from 18mm to 28mm gives an unprecedented level of control in framing, while maintaining exceptional sharpness. But what truly makes it stand out is the way it renders depth—at 28mm, the bokeh is incredibly smooth and milky, adding a rich, cinematic character to close-up shots. Whether capturing the finest textures of food or dynamic liquid motion, this lens elevates every shot with a unique visual signature, making it an essential part of my creative arsenal.
Austen Paul
Director & Visual Content Creator
While I’ve always appreciated the concept of probe lenses, previous options often fell short in image quality, light transmission, and color accuracy. DZOFILM has completely redefined expectations with this release. Delivering impeccable color fidelity and razor-sharp visuals, the Xtract offers outstanding performance. Its T8 aperture ensures excellent usability without demanding excessive lighting. With this lens, DZOFILM has truly restored my confidence in the power and potential of probe lenses.
“
The DZOFilm X-Tract's wide T8 aperture is a game-changer for tabletop and product work, offering incredible depth of field control and capturing stunning details.
”
Baptiste Lejeune
Videographer/Content Creator
Stepping into the world of macro with the DZOFilm X-Tract 18-28mm T8 FF Probe Zoom Lens has been nothing short of impressive. The lens's impressive 2.1:1 magnification and incredibly close 6mm working distance have opened up a universe of detail I never thought possible. It's like being able to touch the subject and still capture its finest textures and details.
On top of that, the build quality of the X-Tract lens is remarkably solid, and its waterproof barrel enables you to explore unique perspectives.
Alex Grima
Food & Drink Director
The Probe Zoom X-Tract is a revolutionary tool for tabletop and macro cinematography. Its ability to smoothly transition from 18mm to 28mm gives an unprecedented level of control in framing, while maintaining exceptional sharpness. But what truly makes it stand out is the way it renders depth—at 28mm, the bokeh is incredibly smooth and milky, adding a rich, cinematic character to close-up shots. Whether capturing the finest textures of food or dynamic liquid motion, this lens elevates every shot with a unique visual signature, making it an essential part of my creative arsenal.
Austen Paul
Director & Visual Content Creator
While I’ve always appreciated the concept of probe lenses, previous options often fell short in image quality, light transmission, and color accuracy. DZOFILM has completely redefined expectations with this release. Delivering impeccable color fidelity and razor-sharp visuals, the Xtract offers outstanding performance. Its T8 aperture ensures excellent usability without demanding excessive lighting. With this lens, DZOFILM has truly restored my confidence in the power and potential of probe lenses.
[ Specification ]
Focal Length
18-28mm
Lens Type
0° Direct
90º Periscope
360º Periscope
Mount
PL
Aperture
T8-T45
Image Circle
φ43.2mm
Construction of Optics
25 Elements in 18 Groups
26 Elements in 19 Groups
27 Elements in 20 Groups
Flange Distance
52mm
Close Focus
(from sensor plane)
0.47m/1ft7in
Close Focus
(from lens front)
6mm
Zoom Ratio
1.55x
Magnification factor (28mm)
2.1X
Iris Control
Manual (72°)
Focus Control
Manual (300°)
Zoom Control
Manual (100°)
Front Dia.
ø29.6mm
37.7*30.58mm
Length
415mm
421mm
(installed on camera)
Horizontal Length:161mm)
Vertical Length:302mm
Iris Blade
10pcs
Gear Pitch
0.8 Mod
Material
Aluminum Alloy
Weight(Product)
≈1090g
≈1132g
≈1144g
Slide to see more →
[ Specification ]
Focal Length
18-28mm
Lens Type
0° Direct
90º Periscope
360º Periscope
Mount
PL
Aperture
T8-T45
Image Circle
φ43.2mm
Construction of Optics
25 Elements in 18 Groups
26 Elements in 19 Groups
27 Elements in 20 Groups
Flange Distance
52mm
Close Focus
(from sensor plane)
0.47m/1ft7in
Close Focus
(from lens front)
6mm
Zoom Ratio
1.55x
Magnification factor (28mm)
2.1X
Iris Control
Manual (72°)
Focus Control
Manual (300°)
Zoom Control
Manual (100°)
Front Dia.
ø29.6mm
37.7*30.58mm
Length
415mm
421mm
(installed on camera)
Horizontal Length:161mm)
Vertical Length:302mm
Iris Blade
10pcs
Gear Pitch
0.8 Mod
Material
Aluminum Alloy
Weight(Product)
≈1090g
≈1132g
≈1144g
Slide to see more →
