Inspire More Imagination
12-25 | 14-30 | 20-55 | 50-125mm T2.8 | Super 35
Inspire More Imagination
12-25 | 14-30 | 20-55 | 50-125mm T2.8 | Super 35

Wider, Closer For Deeper Image Immersion

Get as close as 0.4m (15.74’’) - closer than your arm can reach. This cine zoom lens is perfect for those tight shooting spaces. It delivers exceptional close-up performance with precisely controlled field curvature, allowing cinematographers to create intimate framing that pulls audiences deeper into the narrative.

Wider, Closer For Deeper Image Immersion

Get as close as 0.4m (15.74’’) - closer than your arm can reach. This cine zoom lens is perfect for those tight shooting spaces. It delivers exceptional close-up performance with precisely controlled field curvature, allowing cinematographers to create intimate framing that pulls audiences deeper into the narrative.

A Creative Vision
Inspires Brilliant Ideas

See beyond human vision - the 12-25mm opens up a world wider than your eyes can take in. The perspective effect of ultrawide angle draws attention to the foreground while enhancing the depth of field and tension. Even shooting at maximum wide-open aperture, youll find the distortion stays remarkably in check - ideal for creating majestic and surreal images in film production.

A Creative Vision
Inspires Brilliant Ideas

See beyond human vision - the 12-25mm opens up a world wider than your eyes can take in. The perspective effect of ultra–wide angle draws attention to the foreground while enhancing the depth of field and tension. Even shooting at maximum wide-open aperture, you’ll find the distortion stays remarkably in check - ideal for creating majestic and surreal images in film production.

A Creative Vision
Inspires Brilliant Ideas

See beyond human vision - the 12-25mm opens up a world wider than your eyes can take in. The perspective effect of ultrawide angle draws attention to the foreground while enhancing the depth of field and tension. Even shooting at maximum wide-open aperture, youll find the distortion stays remarkably in check - ideal for creating majestic and surreal images in film production.

Explore
Wider Horizon

DZOFILM Pictor 12-25mm T2.8, the latest Super 35 wide-angle lens, captures wide shots with ease. Team it up with the Pictor 14-30mm, 20-55mm & 50-125mm, and you’ve got a complete arsenal ready for any shot your story demands.

Explore
Wider Horizon

DZOFILM Pictor 12-25mm T2.8, the latest Super 35 wide-angle lens, captures wide shots with ease. Team it up with the Pictor 14-30mm, 20-55mm & 50-125mm, and you’ve got a complete arsenal ready for any shot your story demands.

Explore
Wider Horizon

DZOFILM Pictor 12-25mm T2.8, the latest Super 35 wide-angle lens, captures wide shots with ease. Team it up with the Pictor 14-30mm, 20-55mm & 50-125mm, and you’ve got a complete arsenal ready for any shot your story demands.

Correlated and
Sense of Space

Deeper DOF and wider FOV captures broaderwider background. Each frame of this wide-angle cinema zoom lens becomes a living canvas where characters breathe with their environment, while the zoom lens’s unique characteristics create compelling separation between foreground and background elements. It’s not just about capturing space - it’s about mastering it for maximum dramatic impact.

Correlated and
Sense of Space

Deeper DOF and wider FOV captures broaderwider background. Each frame of this wide-angle cinema zoom lens becomes a living canvas where characters breathe with their environment, while the zoom lens’s unique characteristics create compelling separation between foreground and background elements. It’s not just about capturing space - it’s about mastering it for maximum dramatic impact.

Correlated and
Sense of Space

Deeper DOF and wider FOV captures broaderwider background. Each frame of this wide-angle cinema zoom lens becomes a living canvas where characters breathe with their environment, while the zoom lens’s unique characteristics create compelling separation between foreground and background elements. It’s not just about capturing space - it’s about mastering it for maximum dramatic impact.

Capturing

Turn perspective into power. When you need your shots to speak louder than words, The distortion of the wide angle lens exaggerates emotion of characters and highlights the dramatic expression, turning fleeting moments into powerful visual statements.

Capturing

Turn perspective into power. When you need your shots to speak louder than words, The distortion of the wide angle lens exaggerates emotion of characters and highlights the dramatic expression, turning fleeting moments into powerful visual statements.

Visual Effect

Capturing exaggerating movement, aggrandizes the rhythm of image and enhances the
visual impact in the story.

Visual Effect

Capturing exaggerating movement, aggrandizes the rhythm of image and enhances the visual impact in the story.

Professional Cine Lenses with Concrete Build

DZOFILM is devoted to exploring the aesthetic of film and design of optics. Both mechanics and optics are designed to be compact and versatile, allowing users to enjoy the smooth and precise operation and every shooting moment with Pictor Zoom.
Standard M0.8 Gear Pitch
Focus Rotation Angle
All-metal Mechanical Parts

Professional Cine Lenses with Concrete Build

DZOFILM is devoted to exploring the aesthetic of film and design of optics. Both mechanics and optics are designed to be compact and versatile, allowing users to enjoy the smooth and precise operation and every shooting moment with Pictor Zoom.
Standard M0.8 Gear Pitch
Focus Rotation Angle
All-metal Mechanical Parts

Professional Cine Lenses with Concrete Build

DZOFILM is devoted to exploring the aesthetic of film and design of optics. Both mechanics and optics are designed to be compact and versatile, allowing users to enjoy the smooth and precise operation and every shooting moment with Pictor Zoom.
Standard M0.8 Gear Pitch
Focus Rotation Angle
All-metal Mechanical Parts

Parfocal Design

Center image stay sharp during zooming in or out.
True parfocal performance of a zoom lens means your focus stays locked from close-up to wide, and everything in between, essential for fast-paced documentary shoots. It’s the kind of reliability that lets you focus on storytelling, not focus pulling.

Parfocal Design

Center image stay sharp during zooming in or out.
True parfocal performance of a zoom lens means your focus stays locked from close-up to wide, and everything in between, essential for fast-paced documentary shoots. It’s the kind of reliability that lets you focus on storytelling, not focus pulling.

Minimal Breathing

Thanks to the floating structure, the breathing of Pictor Zoom lenses
are negligible during focusing.

Minimal Breathing

Thanks to the floating structure, the breathing of Pictor Zoom lenses
are negligible during focusing.

Minimal Breathing

Thanks to the floating structure, the breathing of Pictor Zoom lenses
are negligible during focusing.

Versatile In Ultra Compact

At just 1.6kg (3.5 lbs), Pictor zoom can be easily mounted on a crane, jib, tripod, ROV and other moving platforms - Less weight means more creative freedom and safer operation.

Be a better run-and-gun filmmaker with no fear of complicated scenes or quick shooting. When every second counts, one versatile zoom lens for film-making keeps you in the action - no missed moments, no lens swaps. Use Pictor zoom, and never miss an inspiring moment.

Versatile In Ultra Compact

At just 1.6kg (3.5 lbs), Pictor zoom can be easily mounted on a crane, jib, tripod, ROV and other moving platforms - Less weight means more creative freedom and safer operation.

Be a better run-and-gun filmmaker with no fear of complicated scenes or quick shooting. When every second counts, one versatile zoom lens for film-making keeps you in the action - no missed moments, no lens swaps. Use Pictor zoom, and never miss an inspiring moment.

Versatile In Ultra Compact

At just 1.6kg (3.5 lbs), Pictor zoom can be easily mounted on a crane, jib, tripod, ROV and other moving platforms - Less weight means more creative freedom and safer operation.

Be a better run-and-gun filmmaker with no fear of complicated scenes or quick shooting. When every second counts, one versatile zoom lens for film-making keeps you in the action - no missed moments, no lens swaps. Use Pictor zoom, and never miss an inspiring moment.

Gentle Sharpness & Vivid Look

From feature film, commercial, to documentary, Pictor Zoom captures crisp details
while expressing organic look and cinematic texture.

Gentle Sharpness & Vivid Look

From feature film, commercial, to documentary, Pictor Zoom captures crisp details
while expressing organic look and cinematic texture.

Gentle Sharpness & Vivid Look

From feature film, commercial, to documentary, Pictor Zoom captures crisp details
while expressing organic look and cinematic texture.

[Spot Effect] Increases Sense of Separation

Dreamatic Bokeh & Esthetic Transition
During the focus fall-off, 16 blades T2.8 iris generated soft bokeh. The natural transition from focus to de-focus conveys the ambiance and highlights the subject.

[Spot Effect] Increases Sense of Separation

Dreamatic Bokeh & Esthetic Transition
During the focus fall-off, 16 blades T2.8 iris generated soft bokeh. The natural transition from focus to de-focus conveys the ambiance and highlights the subject.

Speed up Your Shooting!

Consistent Design & Higher Efficiency

Delivering consistent color reproduction and mechanical precision to meet rigorous production demands. Standard M0.8 gear rings ensure integration with your existing follow focus system, while multiple mounting options enhance operational flexibility. Every detail is engineered for efficient, professional workflow on set.

Speed up Your Shooting!

Consistent Design & Higher Efficiency

Delivering consistent color reproduction and mechanical precision to meet rigorous production demands. Standard M0.8 gear rings ensure integration with your existing follow focus system, while multiple mounting options enhance operational flexibility. Every detail is engineered for efficient, professional workflow on set.

Speed up Your Shooting!

Consistent Design & Higher Efficiency

Delivering consistent color reproduction and mechanical precision to meet rigorous production demands. Standard M0.8 gear rings ensure integration with your existing follow focus system, while multiple mounting options enhance operational flexibility. Every detail is engineered for efficient, professional workflow on set.

Seek for More Possibility

This cinema zoom lens offers interchangeable PL and EF mounting design. With Octopus adapters, this lens maximize compatibility with cinema cameras featuring X, L, RF, E, and DX mounts, provides more shooting possibilities.

Seek for More Possibility

This cinema zoom lens offers interchangeable PL and EF mounting design. With Octopus adapters, this lens maximize compatibility with cinema cameras featuring X, L, RF, E, and DX mounts, provides more shooting possibilities.

Seek for More Possibility

This cinema zoom lens offers interchangeable PL and EF mounting design. With Octopus adapters, this lens maximize compatibility with cinema cameras featuring X, L, RF, E, and DX mounts, provides more shooting possibilities.
Close-up of camera buttons and dials, monochrome.

Specification

Focal Length
12-25 mm
14-30 mm
20-55 mm
50-125 mm

Colour

BLACK / WHITE

Mount

PL / EF

T-Stop

T2.8-22

Image Circle

φ31.5mm (S35)

Optical Construction

21 Elements in 15 Groups

21 Elements in 17 Groups

18 Elements in 15 Groups

18 Elements in 13 Groups

Flange Distance

52mm (PL) / 44mm (EF)

Close Focus
(from sensor plane)

0.4m/1ft4in

0.6m/2ft

0.8m/2ft8in

Zoom Ratio

2.08X

2.14X

2.75X

2.5X

Iris Control

64.4°

61°

65°

72°

Focus Control

270°

Zoom Control

100°

Front Dia.

φ80mm/3.15"

Length

150mm (PL) 5.9”/ 159mm (EF) 6.26”

173mm (PL) 6.81”/ 181mm (EF) 7.13”

164mm (PL) 6.46”/ 171.9mm (EF) 6.77”

175mm (PL) 6.89”/ 182.9mm (EF) 7.20”

Iris Blade

16

Filter Size

M86*0.75

Gear Pitch

0.8 Mod

Material

Aluminum Alloy

Weight

≈1600g

≈1880g

≈1520g

≈1700g

Slide to see more →
